Smart Wall Light Control Panel

The TIS Sirius 8-button keypad (Model: TIS-SIR-8G) is a wall-mounted push-button switch used in the TIS-BUS home automation system to control various functions like lighting, dimmers, RGB colors, curtains, and scenes.

Key Features and Specifications

• Functionality: Each button can be customized for different functions. A single press can be used for ON/OFF or scene activation, while a long press can control dimming or motorization (e.g., curtains). Double-clicking can offer additional scene options.

• Design & Aesthetics:

  • Features an elegant, classical design with a sleek, modern aesthetic.

  • Buttons are backlit with white and orange LEDs for clear status indication and easy visibility in the dark.

  • Available in various finishes, including black, white, gray, and champagne.

  • Designed for flush mounting and fits standard UK back boxes (86mm x 86mm x 7mm dimensions).

• Technology & Installation:

  • Communicates using the TIS-BUS protocol via a simple 4-core twist pair data cable.

  • Operates on a low voltage of 12-32 V DC, with a current consumption of less than 35 mA at 24 V DC.

  • Offers protection against reverse polarity and ESD (Electrostatic Discharge).

  • Reaction time is approximately 20ms.

• Integration: The keypad acts as a centralized control panel, simplifying home automation by consolidating control over multiple devices and systems (e.g., lighting, climate control, security, A/V). It can be integrated with other smart home systems like Amazon Echo, KNX, and various AC systems through gateways.

This keypad provides a user-friendly interface for managing a smart home environment, combining convenience and energy efficiency with a stylish design.
